MIL-PRF-55182/3 Film Fixed Resistor (NSN 5905-00-211-0091)

Film fixed resistor, 30.1 kilohm, ±0.1% tolerance, per MIL-PRF-55182/3, for the Ticonderoga Class CG 47 Ship.

Part Information

• Design Control Activity: Military Specifications
• Part Number: MIL-PRF-55182/3
• NSN: 5905-00-211-0091
• End Item: Ticonderoga Class CG 47 Ship

Specifications

• Electrical Resistance: 30.100 kilohms
• Resistance Tolerance: -0.100 to 0.100 percent
• Temp Coefficient of Resistance: -50.0 to 50.0 ppm/°C
• Temp Range of Temp Coefficient: -55.0 to 175.0 °C
• Power Dissipation Rating: 0.125 watts, free air
• Ambient Temp at Full Rated Power: 125.0 °C
• Ambient Temp at Zero Percent Rated Power: 175.0 °C
• Enclosure Type: Encapsulated
• Terminal Type: Wire Lead
• MIL-STD-1276 Wire Lead Type Designator: C
• Terminal Length: 1.500 inches nominal
• Body Diameter: 0.125 inches nominal
• Body Length: 0.375 inches nominal
• Reliability Indicator: Established
• Reliability Failure Rate Level: 0.001 percent
• Unpackaged Unit Weight: 0.450 grams
